INTELLIGENT EV DIAGNOSTICS

The MaxiSys Ultra EV is a new generation of intelligent diagnostics for electric, hybrid, gas, and diesel vehicles. The Ultra EV provides a comprehensive analysis of electric and hybrid vehicles with expanded topology mapping and battery pack analysis that can be performed via OBD or directly with included specialty cables and jumpers. The Ultra EV screen displays detailed graphics and in-depth connection guidance to provide safe and secure testing. The 12.9-inch Ultra EV touchscreen tablet comes equipped with the MaxiFlash VCMI (5-in-1) measurement device, Bluetooth-enabled vehicle communication interface and J2534 pass-thru programming device, and a dedicated EVDiag box.

AUTEL MAXISYS ULTRA EV

EV BOX MAKES NEW ENERGY VEHICLE DIAGNOSE

- Diagnose New Energy Vehicles and Hybrid vehicle
- High-voltage System Block Diagnostics
- High-voltage System Block Diagram(zoom out/ in)
- Battery Pack Offline Analysis

ALL FUNCTION OF ULTRA

- Intelligent Diagnostics
- Topology Module Map
- ECU Programming & Coding
- 5in1 VCMI/ 40 Service/ Active Test
- Battery Test (BT506)/ Endoscope (MV108)/ Oscilloscope (MP408)
- CAN FD/ DoIP protocols/ WIFI Print

HIGH-VOLTAGE SYSTEM DIAGNOSTICS

- DTC and FFD
- I/M Readiness
- Live Data
- O2 Sensor Monitor
- On-Board Monitor Vehicles Status
- Component Test/ Replacement
- High-voltage Circuit
- Component Location
- Socket Diagram

BATTERY PACK OFFLINE DIAGNOSIS

Graphical Data Flow:
- Check SOC/ SOH, total voltage, total current, pack voltage delta, and temperature.
- Offer Battery Maintenance Recommendations

For mainstream vehicles such as Tesla, BMW, GM, Audi, BYD, Honda, Toyota, Lexus, etc.

Intelligent Diagnostics

● Tech Services Bulletins: All DTC-related recalls and OEM campaigns will be shown.
● DTC Analysis: Analysis of DTCs and fault descriptions, reasons, influence, and solutions.
● Repair Assist: Help find the fault through step-by-step guidance based on trouble code.
● Repair Tips: Give you information needed to clear the faults, in text or video.
● Component Measurement: Display/analyze the waveform of electronic signals generated.
● Relevant Cases: Show repair processes relevant to specific vehicles and faults in the real world.
● Topology Mapping Technology: fast find the faulty area with easy looking interface.

EV DIAGNOSTIC BOX & 5IN1 VCMI

EV DIAG BOX:
- CAN FD/ DoIP/ D-PDU/ RP1210 Protocols
- EV Diag Box for battery pack diagnostics

5IN1 VCMI:
- Multimeter
- Waveform Generator
- Oscilloscope
- OBDII CAN Bus Check

ECU PROGRAMMING & ECU CODING

- MATCH
component control Modules

- REFRESH
Hidden Functions

- DISABLE
Annoying Function

- CUSTOMIZE
OE-setting

- IMPROVE
Vehicle Performance

40+SERVICES & ACTIVE TEST

- Oil Reset
- EPB
- BMS
- Headlamp
- ABS
- SRS
- SAS
- WIN DR ROOF
- Seats
- Suspension
- Brake Bleed
- Throttle
- Airbag Reset
- Injector
- CHG
- WinAndDoor
- Limit
- etc.

SPECIFICATION

- OS: Android 7.0
- Processor: Samsung Exynos8895V
- Memory: 4GB RAM + 256GB ROM
- Display Size: 12.9 inches
- Resolution: 2732 x 2048
- Battery: 18000mAh
